Custom Tube adapter STL file ⌀ 60–15 mm (Length: 165 mm) 📦#2400

STL Download STL 1
Create a new model expert
from scratch search for a model
Inline tube reducer ⌀60 mm to ⌀15 mm in STL 3D format. Final length of this junction is 165 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 25 mm, the smaller one of 40 mm. The axes of the tubes are offset by 20 mm. The ends are rounded on the outside.
Generation date: 2025-10-12
3D Model Tube adapter STL file ⌀ 60–15 mm (Length: 165 mm)

3D model download

Free
  • inline-tube-adapter-lenA25mm-d_model2400-nb0_dd{id}.stl : 4 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 25 mm (≃0.98 in)
#2 side A outer diameter 60 mm (≃2 3/8 in)
#3 side A thickness 2 mm (≃0.08 in)
#4 side B length 40 mm (≃1 9/16 in)
#5 side B outer diameter 15 mm (≃0.59 in)
#6 side B thickness 2 mm (≃0.08 in)
#7 transition length 100 mm (≃3 15/16 in)
#8 axis offset 20 mm (≃0.79 in)
#9 ends fillet fillet on the outside
Metadata Value
inner diameter (side A) 56 mm (≃2.20 in)
inner diameter (side B) 11 mm (≃7/16 in)
total length 165 mm (≃6 1/2 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
