Multi-compartment box with color-coded collars
Number of 3D models generated: 25
Category: accessories
Loading...
View of object #0
(model #1222)
Photos of various 3D printed models
Keywords: box, enclosure, compartment, slot, storage, sorting, sorting box, organizer, pillbox, color, marker, code, collar, ring
This template generates compartmentalized storage boxes with color markers. It is an evolution of the Compartment box template.
In addition to the basic parameters such as the number of rows, the number of columns, and the compartment dimensions, it is possible here to define a ring color for each row. Each ring is 1 mm thick and 1 mm deep.
You can also set a fillet inside the compartments to make it easier to grab objects.
By setting a maximum fillet value, it is possible to obtain almost cylindrical cavities, as seen in the model Compartment box with color codes: 36 compartments of 14×14×7 mm (#1185), for example.
This is the first multi-color template published on the platform. You can learn more about this template in the dedicated blog post.
