Multi compartment storage box
Number of 3D models generated: 31
Category: accessories
Loading...
(model #1150)
Photos of some models once 3D printed
This template generates compartmentalized storage boxes.
The parameters are the number of rows, the number of columns, the compartment dimensions, and the wall thickness (including the bottom).
The compartments can include an internal fillet, for example to make it easier to pick up small objects if needed.
The box features a 0.8 mm fillet on all its edges.
This template can generate a simple box (#1059) without compartments, by setting the number of columns and number of rows to 1.
This template can produce quasi-cylindrical compartments (#1063) when the width and length are equal, and the compartment fillet is just slightly smaller than half of those dimensions.
Find more information in our dedicated blog post about 3D compartmentalized boxes.
Keywords: box, casing, compartment, slot, storage, organizing, locker, sortingbox, organizer, pillbox, dispenser
Customizable parameters
| name | unit | |
|---|---|---|
| #1 | number of rows | |
| #1 | number of columns | |
| #1 | compartment length | mm |
| #1 | compartment width | mm |
| #1 | compartment height | mm |
| #1 | wall thickness | mm |
| #1 | compartment fillet (radius) | mm |
The height of the compartments corresponds to their depth.
Parameter #7 compartment fillet (radius) applies to the base and sides of the compartments, not the top edges.
Illustration of the parameters
Model search and on-demand generation
This form allows you to find existing models based on the parameters of your choice.
You can leave fields empty; they will be ignored.
The results are displayed from the most relevant to the least relevant.
A star indicates that the model exactly matches your search criteria or is very close.
On-demand generation is available for this template. If the model does not exist, on-demand generation will be offered.
