Custom Box STL file with dimensions 30×30×30 mm 📦#1076

STL Download STL 8
Create a new model advanced
from scratch search for a model
This STL 3D model includes a single cavity measuring 30×30×30mm. The total dimensions are 40×40×35mm. The fillet of 12mm improves usability inside the box. The walls are particularly thick.
Generation date: 2025-06-02
3D Model Box STL file with dimensions 30×30×30 mm

3D model download

Free
  • multi-compartment-storage-box-_model1076-nb0_dd{id}.stl : 156.9 Ko
STL Mesh quality : not defined
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Multi-compartment storage box template, with the following values:
Parameter Value
#1 number of rows 1
#2 number of columns 1
#3 compartment length 30 mm (≃1 3/16 in)
#4 compartment width 30 mm (≃1 3/16 in)
#5 compartment height 30 mm (≃1 3/16 in)
#6 wall thickness 5 mm (≃3/16 in)
#7 compartment fillet (radius) 12 mm (≃0.47 in)
Metadata Value
total length 40 mm (≃1 9/16 in)
total width 40 mm (≃1 9/16 in)
total height 35 mm (≃1 3/8 in)
number of slots 1
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 number of rows nbR
#2 number of columns nbC
#3 compartment length coL
#4 compartment width coW
#5 compartment height coH
#6 wall thickness waT
#7 compartment fillet (radius) coF
