This template generates cases with screw-mounted lids.
In addition to the basic parameters (length, width, height), it is possible to define a cooling level on the case, the lid, or both.
Margins for the screw housing and the assembly area are also available for adjustment depending on the material used.
The case requires the use of 4 socket head cap screws (DIN 912) with a diameter of M3.
In the case of FFF 3D printing, minimal support structures will be required around the screw head recesses in the lid.
Find more information about this template in the dedicated blog post.
Keywords: enclosure with screw mounted lid, enclosure with screw fastened lid, enclosure with screw closure, box with screw on lid
Search
Additional information
Note that parameters #1 length and #2 width refer to the external dimensions. If you are working with internal dimensions, you will need to add twice the wall thickness.
Parameter #6 screw margin adjusts the diameter of the cylinder into which the screws thread are inserted in the base. By default, its diameter is 3 mm. Depending on the material used, you will likely need to adjust this value so that the thread cuts into the material properly (not too much, not too little).
Parameter #7 fit clearance defines the gap between the two parts for assembly. At 0, both objects are modeled with no clearance at all. It is often recommended to add 0.1 to 0.2 mm for a smooth fit.
Parameter #8 cooling level determines the strength of the ventilation. At 0, no cutouts are applied. At 10, the maximum possible number of cutouts is generated.
-
2025-07-04 (last model before revision: #1140) :
parameter #6 screw margin : has been updated from "-0.4 to 0.4" to "-0.2 to 0.2"
parameter #7 fit clearance : has been updated from "0 to 0.6" to "0 to 0.2" -
2025-07-07 (last model before revision: #1149) :
parameter #5 wall thickness : has been updated from "2.0 to 5.0" to "2.0 to 6.0"
- The thickness of the upper lid shell is always 5 mm.
Illustration of the parameters
