Multi-compartment box: 6 compartments of 50×80×100 mm 📦#1091
1 object(s) - format STL
Loading...
◀
▶
Values for this model
| Parameter | Value | Unit | Label | |
|---|---|---|---|---|
| #1 | number of raws | 2 | nbR | |
| #2 | number of columns | 3 | nbC | |
| #3 | compartment length | 50 | mm | coL |
| #4 | compartment width | 80 | mm | coW |
| #5 | compartment height | 100 | mm | coH |
| #6 | wall thickness | 4 | mm | waT |
| #7 | compartment fillet (radius) | 2 | mm | coF |
Representation of the parameters
Notes:
The height of the compartments corresponds to their depth.
Parameter #7 compartment fillet (radius) applies to the base and sides of the compartments, not the top edges.
To get the total height of the box, apply the formula: coH + waT
3D model download
3D file(s) name:
multi-compartment-storage-box-nbR2-nbC3-coL50mm-coW80mm-coH100mm-waT4mm-coF2mm_model1091-nb0_dd{id}.stl
Download format: zip
