Box with dimensions 50×50×60 mm 📦#1059

1 object(s) - format STL

This printable mono-compartment box features a single cavity measuring 50×50×60mm. External size are 58×58×64mm. The fillet of 3mm helps with item retrieval inside the compartment. The separators are particularly reinforced.

◀ ▶

3D Model Box with dimensions 50×50×60 mm

Values for this model

	Parameter	Value	Unit	Label
#1	number of raws	1		nbR
#2	number of columns	1		nbC
#3	compartment length	50	mm	coL
#4	compartment width	50	mm	coW
#5	compartment height	60	mm	coH
#6	wall thickness	4	mm	waT
#7	compartment fillet (radius)	3	mm	coF

Representation of the parameters

Notes:

The height of the compartments corresponds to their depth.

Parameter #7 compartment fillet (radius) applies to the base and sides of the compartments, not the top edges.

To get the total height of the box, apply the formula: coH + waT

3D model download

3D file(s) name:

multi-compartment-storage-box-nbR1-nbC1-coL50mm-coW50mm-coH60mm-waT4mm-coF3mm_model1059-nb0_dd{id}.stl

Download format: zip

License: CC BY - Creative commons

(attribution - commercial use allowed)

Free download
