Multi-compartment box STL 3D file: 49 compartments of 30×30×40 mm 📦#1066

STL Download STL
Create a new model:
from scratch search for a model
This STL file includes 49 cavities measuring 30×30×40mm each. External size are 226×226×42mm. A 4mm fillet applied to all compartments make it easier to grasp items stored in the compartments.
Generation date: 2025-06-01
3D Model Multi-compartment box STL 3D file: 49 compartments of 30×30×40 mm

3D model download

Free
  • multi-compartment-storage-box-_model1066-nb0_dd{id}.stl : 4.4 Mo
STL Mesh quality : not defined
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Values for this model

This model was generated by the Multi-compartment storage box template, with the following values:
Parameter Value
#1 number of rows 7
#2 number of columns 7
#3 compartment length 30 mm
#4 compartment width 30 mm
#5 compartment height 40 mm
#6 wall thickness 2 mm
#7 compartment fillet (radius) 4 mm
illustration of the parameters
Representation of the parameters

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 number of rows nbR
#2 number of columns nbC
#3 compartment length coL
#4 compartment width coW
#5 compartment height coH
#6 wall thickness waT
#7 compartment fillet (radius) coF
