Custom Multi-compartment box STL 3D file: 64 compartments of 14×14×40 mm 📦#3930

STL Download STL 1
Create a new model:
from scratch search for a model
This STL 3D model provides 64 slots measuring 14×14×40mm each. The total dimensions of the box are 130×130×42mm. Fillets of 3mm applied to all compartments help with item retrieval stored in slots.
Generation date: 2025-11-27
3D Model Multi-compartment box STL 3D file: 64 compartments of 14×14×40 mm

3D model download

Free
  • multi-compartment-storage-box-_model3930-nb0_dd{id}.stl : 5.7 Mo
STL Mesh quality : Linear deflection 0.5 Angular deflection 0.3
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Values for this model

This model was generated by the Multi-compartment storage box template, with the following values:
Parameter Value
#1 number of rows 8
#2 number of columns 8
#3 compartment length 14 mm (≃9/16 in)
#4 compartment width 14 mm (≃9/16 in)
#5 compartment height 40 mm (≃1 9/16 in)
#6 wall thickness 2 mm (≃0.08 in)
#7 compartment fillet (radius) 3 mm (≃1/8 in)
Metadata Value
total length 130 mm (≃5 1/8 in)
total width 130 mm (≃5 1/8 in)
total height 42 mm (≃1.65 in)
number of slots 64
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 number of rows nbR
#2 number of columns nbC
#3 compartment length coL
#4 compartment width coW
#5 compartment height coH
#6 wall thickness waT
#7 compartment fillet (radius) coF
