Multi-compartment box: 36 compartments of 17×17×80 mm 📦#1063

1 object(s) - format STL

This printable multi-compartment box features 36 compartments measuring 17×17×80 mm each, with an almost cylindrical shape. Overall dimensions are 116×116×82 mm.
Loading...
3D Model Multi compartment storage box - Model #1063

Values for this model

Parameter Value Unit Label
#1 number of raws 6 nbR
#2 number of columns 6 nbC
#3 compartment length 17 mm coL
#4 compartment width 17 mm coW
#5 compartment height 80 mm coH
#6 wall thickness 2 mm waT
#7 compartment fillet (radius) 8.4 mm coF
illustration of the parameters
Representation of the parameters
Notes:

The height of the compartments corresponds to their depth.

Parameter #7 compartment fillet (radius) applies to the base and sides of the compartments, not the top edges.

To get the total height of the box, apply the formula: coH + waT

3D model download

3D file(s) name:

multi-compartment-storage-box-nbR6-nbC6-coL17mm-coW17mm-coH80mm-waT2mm-coF8.4mm_model1063-nb0_dd{id}.stl

Download format: zip
(attribution - commercial use allowed)
Free download
🥥🥥🥝🍍🍍🥝🥝🥥🥥
