Custom Multi-compartment box STL file: 36 compartments of 17×17×45 mm 📦#3714

STL Download STL 1
Create a new model advanced
from scratch search for a model
This printable multi-compartment box provides 36 storage spaces measuring 17×17×45mm each. The total dimensions are 116×116×47mm. Fillets of 8.4mm applied to each compartment help with item retrieval stored in the compartments.
Generation date: 2025-11-26
3D Model Multi-compartment box STL file: 36 compartments of 17×17×45 mm

3D model download

Free
  • multi-compartment-storage-box-_model3714-nb0_dd{id}.stl : 3.2 Mo
STL Mesh quality : Linear deflection 0.5 Angular deflection 0.3
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Multi-compartment storage box template, with the following values:
Parameter Value
#1 number of rows 6
#2 number of columns 6
#3 compartment length 17 mm (≃0.67 in)
#4 compartment width 17 mm (≃0.67 in)
#5 compartment height 45 mm (≃1.77 in)
#6 wall thickness 2 mm (≃0.08 in)
#7 compartment fillet (radius) 8.4 mm (≃0.33 in)
Metadata Value
total length 116 mm (≃4 9/16 in)
total width 116 mm (≃4 9/16 in)
total height 47 mm (≃1.85 in)
number of slots 36
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 number of rows nbR
#2 number of columns nbC
#3 compartment length coL
#4 compartment width coW
#5 compartment height coH
#6 wall thickness waT
#7 compartment fillet (radius) coF
