Custom Tube adapter STL 3D file ⌀ 90–68 mm (Length: 90 mm) 📦#1188

STL Download STL 2
Create a new model:
from scratch search for a model
Tube connector ⌀90 mm to ⌀68 mm in STL 3D format. Final length of this junction is 90 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 15 mm, the smaller one of 30 mm. The two axes of the tubes are offset by 10 mm. The ends are not rounded.
Generation date: 2025-07-11
3D Model Tube adapter STL 3D file ⌀ 90–68 mm (Length: 90 mm)

3D model download

Free
  • inline-tube-adapter-lenA15mm-d_model1188-nb0_dd{id}.stl : 2.1 Mo
STL Mesh quality : not defined
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 15 mm (≃0.59 in)
#2 side A outer diameter 90 mm (≃3.54 in)
#3 side A thickness 2 mm (≃0.08 in)
#4 side B length 30 mm (≃1 3/16 in)
#5 side B outer diameter 68 mm (≃2 11/16 in)
#6 side B thickness 2 mm (≃0.08 in)
#7 transition length 45 mm (≃1.77 in)
#8 axis offset 10 mm (≃0.39 in)
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 86 mm (≃3 3/8 in)
inner diameter (side B) 64 mm (≃2.52 in)
total length 90 mm (≃3.54 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
