Custom Tube adapter STL file ⌀ 100–60 mm (Length: 70 mm) 📦#1115

STL Download STL 12
Create a new model:
from scratch search for a model
Straight tube adapter ⌀100 mm to ⌀60 mm in STL format. Length of this fitting is 70 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a sleeve length of 10 mm, the smaller one of 20 mm. The two axes of the tubes are off-center by 15 mm. The ends are rounded on the outside to make tube connection easier.
Generation date: 2025-06-25
3D Model Tube adapter STL file ⌀ 100–60 mm (Length: 70 mm)

3D model download

Free
  • inline-tube-adapter-lenA10mm-d_model1115-nb0_dd{id}.stl : 1.3 Mo
STL Mesh quality : not defined
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Photos of the model once printed

Tube adapter STL file ⌀ 100–60 mm (Length: 70 mm)

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 10 mm (≃0.39 in)
#2 side A outer diameter 100 mm (≃3 15/16 in)
#3 side A thickness 2 mm (≃0.08 in)
#4 side B length 20 mm (≃0.79 in)
#5 side B outer diameter 60 mm (≃2 3/8 in)
#6 side B thickness 2 mm (≃0.08 in)
#7 transition length 40 mm (≃1 9/16 in)
#8 axis offset 15 mm (≃0.59 in)
#9 ends fillet fillet on the outside
Metadata Value
inner diameter (side A) 96 mm (≃3.78 in)
inner diameter (side B) 56 mm (≃2.20 in)
total length 70 mm (≃2 3/4 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
