Custom Tube adapter STL 3D file ⌀ 140–100 mm (Length: 80 mm) 📦#3857

STL Download STL
Create a new model:
from scratch search for a model
Inline tubing adapter ⌀140 mm to ⌀100 mm in STL 3D format. Final length of this junction is 80 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 20 mm, the smaller one of 30 mm. The two axes of the tubes are offset by 19.9 mm. The ends feature an external fillet to facilitate the connection of the two tubes.
Generation date: 2025-11-27
3D Model Tube adapter STL 3D file ⌀ 140–100 mm (Length: 80 mm)

3D model download

Free
  • inline-tube-adapter-lenA20mm-d_model3857-nb0_dd{id}.stl : 11.4 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 20 mm (≃0.79 in)
#2 side A outer diameter 140 mm (≃5 1/2 in)
#3 side A thickness 3 mm (≃1/8 in)
#4 side B length 30 mm (≃1 3/16 in)
#5 side B outer diameter 100 mm (≃3 15/16 in)
#6 side B thickness 3 mm (≃1/8 in)
#7 transition length 30 mm (≃1 3/16 in)
#8 axis offset 19.9 mm (≃0.78 in)
#9 ends fillet fillet on the outside
Metadata Value
inner diameter (side A) 134 mm (≃5.28 in)
inner diameter (side B) 94 mm (≃3 11/16 in)
total length 80 mm (≃3.15 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
