Inline tube adapter ⌀150 mm to ⌀120 mm in STL format. Final length of this fitting is 108 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a length of 22.5 mm, the smaller one of 35.5 mm. The axes of the tubes are offset by 14 mm. The ends have a fillet on the outside to make tube connection easier.
Generation date: 2025-06-21
3D Model Tube adapter STL 3D file ⌀ 150–120 mm (Length: 108 mm)

3D model download

Free
  • inline-tube-adapter-lenA22.5mm_model1105-nb0_dd{id}.stl : 1.2 Mo
STL Mesh quality : not defined
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 22.5 mm
#2 side A outer diameter 150 mm
#3 side A thickness 5 mm
#4 side B length 35.5 mm
#5 side B outer diameter 120 mm
#6 side B thickness 5 mm
#7 transition length 50 mm
#8 axis offset 14 mm
#9 ends fillet fillet on the outside
illustration of the parameters
Representation of the parameters

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
