Custom Tube adapter STL 3D file ⌀ 140–93 mm (Length: 110 mm) 📦#1432

STL Download STL
Create a new model:
from scratch search for a model
Tube connector ⌀140 mm to ⌀93 mm in STL 3D format. Length of this adapter is 110 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a sleeve length of 30 mm, the smaller one of 30 mm as well. The ends are raw.
Generation date: 2025-08-26
3D Model Tube adapter STL 3D file ⌀ 140–93 mm (Length: 110 mm)

3D model download

Free
  • inline-tube-adapter-lenA30mm-d_model1432-nb0_dd{id}.stl : 4 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 30 mm (≃1 3/16 in)
#2 side A outer diameter 140 mm (≃5 1/2 in)
#3 side A thickness 5 mm (≃3/16 in)
#4 side B length 30 mm (≃1 3/16 in)
#5 side B outer diameter 93 mm (≃3.66 in)
#6 side B thickness 5 mm (≃3/16 in)
#7 transition length 50 mm (≃1.97 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 130 mm (≃5 1/8 in)
inner diameter (side B) 83 mm (≃3.27 in)
total length 110 mm (≃4.33 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
