Tube adapter STL 3D file ⌀ 75–50 mm (Length: 100 mm) 📦#1238

STL Download STL
Create a new model:
from scratch search for a model
Tube fitting ⌀75 mm to ⌀50 mm in STL format. Total length of this sleeve is 100 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 20 mm, the smaller one of 20 mm as well. The axes of the tubes are off-center by 12.4 mm. The ends have no fillet.
Generation date: 2025-07-20
3D Model Tube adapter STL 3D file ⌀ 75–50 mm (Length: 100 mm)

3D model download

Free
  • inline-tube-adapter-lenA20mm-d_model1238-nb0_dd{id}.stl : 197 Ko
STL Mesh quality : not defined
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 20 mm
#2 side A outer diameter 75 mm
#3 side A thickness 2 mm
#4 side B length 20 mm
#5 side B outer diameter 50 mm
#6 side B thickness 2 mm
#7 transition length 60 mm
#8 axis offset 12.4 mm
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 71 mm
inner diameter (side B) 46 mm
total length 100 mm
illustration of the parameters
Representation of the parameters

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
