Tube adapter STL file ⌀ 60–30 mm (Length: 140 mm) 📦#1100

STL Download STL
Create a new model:
from scratch search for a model
Straight sleeve ⌀60 mm to ⌀30 mm in STL 3D format. Final length of this adapter is 140 mm. The larger-diameter tube has a thickness of 4 mm and a sleeve length of 20 mm. The smaller-diameter tube has a thickness of 3 mm and a length of 20 mm as well. The two axes of the tubes are off-center by 13.9 mm. The ends have no fillet.
Generation date: 2025-06-17
3D Model Tube adapter STL file ⌀ 60–30 mm (Length: 140 mm)

3D model download

Free
  • inline-tube-adapter-lenA20mm-d_model1100-nb0_dd{id}.stl : 153.7 Ko
STL Mesh quality : not defined
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Photos of the model once printed

Tube adapter STL file ⌀ 60–30 mm (Length: 140 mm)

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 20 mm
#2 side A outer diameter 60 mm
#3 side A thickness 4 mm
#4 side B length 20 mm
#5 side B outer diameter 30 mm
#6 side B thickness 3 mm
#7 transition length 100 mm
#8 axis offset 13.9 mm
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 52 mm
inner diameter (side B) 24 mm
total length 140 mm
illustration of the parameters
Representation of the parameters

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
