Tube adapter ⌀100 mm to ⌀20 mm in STL format. Final length of this reducer is 110 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a length of 10 mm, the smaller one of 30 mm. The ends are not rounded.
Generation date: 2025-11-16
3D Model Tube adapter STL 3D file ⌀ 100–20 mm (Length: 110 mm)

3D model download

Free
  • inline-tube-adapter-lenA10mm-d_model3343-nb0_dd{id}.stl : 2.9 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 10 mm (≃0.39 in)
#2 side A outer diameter 100 mm (≃3 15/16 in)
#3 side A thickness 3 mm (≃1/8 in)
#4 side B length 30 mm (≃1 3/16 in)
#5 side B outer diameter 20 mm (≃0.79 in)
#6 side B thickness 3 mm (≃1/8 in)
#7 transition length 70 mm (≃2 3/4 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 94 mm (≃3 11/16 in)
inner diameter (side B) 14 mm (≃9/16 in)
total length 110 mm (≃4.33 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
