Custom Tubing adapter STL 3D file ⌀ 100–34 mm (Length: 115 mm) 📦#3776

STL Download STL
Create a new model:
from scratch search for a model
Straight tube connector ⌀100 mm to ⌀34 mm in STL format. Length of this adapter is 115 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 5 mm, the smaller one of 30 mm. The ends have no fillet.
Generation date: 2025-11-26
3D Model Tubing adapter STL 3D file ⌀ 100–34 mm (Length: 115 mm)

3D model download

Free
  • inline-tube-adapter-lenA5mm-di_model3776-nb0_dd{id}.stl : 1.5 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 5 mm (≃3/16 in)
#2 side A outer diameter 100 mm (≃3 15/16 in)
#3 side A thickness 2 mm (≃0.08 in)
#4 side B length 30 mm (≃1 3/16 in)
#5 side B outer diameter 34 mm (≃1.34 in)
#6 side B thickness 2 mm (≃0.08 in)
#7 transition length 80 mm (≃3.15 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 96 mm (≃3.78 in)
inner diameter (side B) 30 mm (≃1 3/16 in)
total length 115 mm (≃4.53 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
