Custom Tubing adapter STL file ⌀ 77–30 mm (Length: 140 mm) 📦#3916

STL Download STL 1
Create a new model:
from scratch search for a model
Tube fitting ⌀77 mm to ⌀30 mm in STL format. Length of this sleeve is 140 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a length of 30 mm, the smaller one of 50 mm. The ends are raw.
Generation date: 2025-11-27
3D Model Tubing adapter STL file ⌀ 77–30 mm (Length: 140 mm)

3D model download

Free
  • inline-tube-adapter-lenA30mm-d_model3916-nb0_dd{id}.stl : 1.3 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 30 mm (≃1 3/16 in)
#2 side A outer diameter 77 mm (≃3.03 in)
#3 side A thickness 3 mm (≃1/8 in)
#4 side B length 50 mm (≃1.97 in)
#5 side B outer diameter 30 mm (≃1 3/16 in)
#6 side B thickness 3 mm (≃1/8 in)
#7 transition length 60 mm (≃2 3/8 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 71 mm (≃2.80 in)
inner diameter (side B) 24 mm (≃15/16 in)
total length 140 mm (≃5 1/2 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil

Related 3D models

To search for a model based on your own parameters, go to the template page Inline tube adapter

Tube adapter STL file ⌀ 40–35 mm (Length: 130 mm) (📦 #1856)

1 object(s) - format STL
Tube adapter STL file ⌀ 40–35 mm (Length: 130 mm)
Inline tube reducer ⌀40 mm to ⌀35 mm in STL 3D format. Length of this adapter is 130 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a length of 30 mm, the smaller one of 50 mm. The ends are raw.
Parameter Value Unit
side A length 30 mm
side A outer diameter 40 mm
side A thickness 3 mm
side B length 50 mm
side B outer diameter 35 mm
side B thickness 3 mm
transition length 50 mm
axis offset 0 mm
ends fillet no fillet

Tube adapter STL 3D file ⌀ 76–30 mm (Length: 170 mm) (📦 #3914)

1 object(s) - format STL
Tube adapter STL 3D file ⌀ 76–30 mm (Length: 170 mm)
Tube coupler ⌀76 mm to ⌀30 mm in STL 3D format. Total length of this coupler is 170 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a length of 30 mm, the smaller one of 50 mm. The ends are raw.
Parameter Value Unit
side A length 30 mm
side A outer diameter 76 mm
side A thickness 3 mm
side B length 50 mm
side B outer diameter 30 mm
side B thickness 3 mm
transition length 90 mm
axis offset 0 mm
ends fillet no fillet

Tube adapter STL 3D file ⌀ 100–20 mm (Length: 110 mm) (📦 #3343)
