Custom Tube adapter STL file ⌀ 75–66 mm (Length: 120 mm) 📦#3926

STL Download STL 3
Create a new model expert
from scratch search for a model
Tube adapter ⌀75 mm to ⌀66 mm in STL 3D format. Length of this connector is 120 mm. The larger-diameter tube has a thickness of 4 mm and a length of 40 mm. The smaller-diameter tube has a thickness of 3 mm and a length of 40 mm as well. The ends have no fillet.
Generation date: 2025-11-27
3D Model Tube adapter STL file ⌀ 75–66 mm (Length: 120 mm)

3D model download

Free
  • inline-tube-adapter-lenA40mm-d_model3926-nb0_dd{id}.stl : 588.5 Ko
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 40 mm (≃1 9/16 in)
#2 side A outer diameter 75 mm (≃2 15/16 in)
#3 side A thickness 4 mm (≃0.16 in)
#4 side B length 40 mm (≃1 9/16 in)
#5 side B outer diameter 66 mm (≃2.60 in)
#6 side B thickness 3 mm (≃1/8 in)
#7 transition length 40 mm (≃1 9/16 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 67 mm (≃2 5/8 in)
inner diameter (side B) 60 mm (≃2 3/8 in)
total length 120 mm (≃4.72 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
