Custom Tubing adapter STL 3D file ⌀ 155–103 mm (Length: 130 mm) 📦#3409

STL Download STL
Create a new model:
from scratch search for a model
Inline tube junction ⌀155 mm to ⌀103 mm in STL format. Final length of this reducer is 130 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a length of 60 mm, the smaller one of 40 mm. The two axes of the tubes are offset by 25.4 mm. The ends have a fillet to facilitate the connection of the two tubes.
Generation date: 2025-11-18
3D Model Tubing adapter STL 3D file ⌀ 155–103 mm (Length: 130 mm)

3D model download

Free
  • inline-tube-adapter-lenA60mm-d_model3409-nb0_dd{id}.stl : 16.3 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 60 mm (≃2 3/8 in)
#2 side A outer diameter 155 mm (≃6.10 in)
#3 side A thickness 3 mm (≃1/8 in)
#4 side B length 40 mm (≃1 9/16 in)
#5 side B outer diameter 103 mm (≃4 1/16 in)
#6 side B thickness 3 mm (≃1/8 in)
#7 transition length 30 mm (≃1 3/16 in)
#8 axis offset 25.4 mm (1 in)
#9 ends fillet fillet on both inside
and outside
Metadata Value
inner diameter (side A) 149 mm (≃5 7/8 in)
inner diameter (side B) 97 mm (≃3 13/16 in)
total length 130 mm (≃5 1/8 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
