Tube adapter ⌀ 104–50 mm (Length: 85 mm) 📦#1457

Tube junction ⌀104 mm to ⌀50 mm in STL format. Length of this adapter is 85 mm. The thickness of the tubes is identical: 2 mm. The axes of the tubes are off-center. The ends feature an internal fillet to make tube connection easier.

Generation date: 2025-08-27

3D Model Tube adapter ⌀ 104–50 mm (Length: 85 mm)

3D model download

Free

Download format: zip : 13.1 Mo (1 file(s))

inline-tube-adapter-lenA30mm-d_model1457-nb0_dd{id}.stl : 13.1 Mo

STL Mesh quality : 0.05 0.05

License: CC BY - Creative commons

(attribution - commercial use allowed)

Values for this model

This model was generated by the Inline tube adapter template, with the following values:

	Template parameter	Value	Unit	Label
#1	side A length	30	mm	lenA
#2	side A outer diameter	104	mm	diA
#3	side A thickness	2	mm	thA
#4	side B length	25	mm	lenB
#5	side B outer diameter	50	mm	diB
#6	side B thickness	2	mm	thB
#7	transition length	30	mm	tra
#8	axis offset	26	mm	ofs
#9	ends fillet	2	0,1,2,3	fil

Representation of the parameters

See details

The transition refers to the connection interface between the two tubes. It defines the total length of the adapter, which is equal to the sum of the tube lengths plus the length of the transition.

Details for parameter #9 ends fillet:

0: no fillet
1: fillet on the outside
2: fillet on the inside
3: fillet on both inside and outside

Related 3D models

To search for a model based on your own parameters, go to the template page Inline tube adapter
