Custom Tube adapter STL file ⌀ 104–50 mm (Length: 85 mm) 📦#1456

STL Download STL 1
Create a new model:
from scratch search for a model
Diameter adapter ⌀104 mm to ⌀50 mm in STL 3D format. Total length of this sleeve is 85 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a sleeve length of 30 mm, the smaller one of 25 mm. The two axes of the tubes are offset by 25.4 mm. The ends feature an internal fillet.
Generation date: 2025-08-27
3D Model Tube adapter STL file ⌀ 104–50 mm (Length: 85 mm)

3D model download

Free
  • inline-tube-adapter-lenA30mm-d_model1456-nb0_dd{id}.stl : 12.9 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 30 mm (≃1 3/16 in)
#2 side A outer diameter 104 mm (≃4.09 in)
#3 side A thickness 2 mm (≃0.08 in)
#4 side B length 25 mm (≃0.98 in)
#5 side B outer diameter 50 mm (≃1.97 in)
#6 side B thickness 2 mm (≃0.08 in)
#7 transition length 30 mm (≃1 3/16 in)
#8 axis offset 25.4 mm (1 in)
#9 ends fillet fillet on the inside
Metadata Value
inner diameter (side A) 100 mm (≃3 15/16 in)
inner diameter (side B) 46 mm (≃1 13/16 in)
total length 85 mm (≃3.35 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
