Tube adapter STL file ⌀ 100–51 mm (Length: 160 mm) 📦#1098

STL Download STL
Create a new model:
from scratch search for a model
Diameter adapter ⌀100 mm to ⌀51 mm in STL format. Total length of this reducer is 160 mm. The larger-diameter tube has a thickness of 4 mm and a length of 60 mm. The smaller-diameter tube has a thickness of 5 mm and a length of 40 mm. The axes of the tubes are off-center by 25.4 mm. The ends feature a fillet to facilitate the connection of the two tubes.
Generation date: 2025-06-16
3D Model Tube adapter STL file ⌀ 100–51 mm (Length: 160 mm)

3D model download

Free
  • inline-tube-adapter-lenA60mm-d_model1098-nb0_dd{id}.stl : 1.6 Mo
STL Mesh quality : not defined
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Photos of the model once printed

Tube adapter STL file ⌀ 100–51 mm (Length: 160 mm)

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 60 mm
#2 side A outer diameter 100 mm
#3 side A thickness 4 mm
#4 side B length 40 mm
#5 side B outer diameter 51 mm
#6 side B thickness 5 mm
#7 transition length 60 mm
#8 axis offset 25.4 mm
#9 ends fillet fillet on both inside
and outside
Metadata Value
inner diameter (side A) 92 mm
inner diameter (side B) 41 mm
total length 160 mm
illustration of the parameters
Representation of the parameters

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
