Custom Tubing adapter STL file ⌀ 90–49 mm (Length: 120 mm) 📦#9323

STL Download STL 1
Create a new model expert
from scratch search for a model
Inline tube reducer ⌀90 mm to ⌀49 mm in STL format. Total length of this junction is 120 mm. The thickness of the tubes is identical: 4 mm. The larger-diameter tube has a length of 50 mm, the smaller one of 40 mm. The axes of the tubes are off-center by 20 mm. The ends are raw.
Generation date: 2026-06-06
3D Model Tubing adapter STL file ⌀ 90–49 mm (Length: 120 mm)

3D model download

Free
  • inline-tube-adapter-lenA50mm-d_model9323-nb0_dd{id}.stl : 5.9 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 50 mm (≃1.97 in)
#2 side A outer diameter 90 mm (≃3.54 in)
#3 side A thickness 4 mm (≃0.16 in)
#4 side B length 40 mm (≃1 9/16 in)
#5 side B outer diameter 49 mm (≃1 15/16 in)
#6 side B thickness 4 mm (≃0.16 in)
#7 transition length 30 mm (≃1 3/16 in)
#8 axis offset 20 mm (≃0.79 in)
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 82 mm (≃3.23 in)
inner diameter (side B) 41 mm (≃1 5/8 in)
total length 120 mm (≃4.72 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
