Custom Round-to-Rectangular Tube Adapter STL file ⌀100 mm to 120×40 mm, thickness 2 mm + offset 📦#1938

STL Download STL 1
Create a new model expert
from scratch search for a model
3D file in STL format of a round-to-rectangular adapter with an external diameter of ⌀100 mm and a rectangular section with inner dimensions 120×40 mm. The shell thickness is 2 mm and the total length is 175 mm. The adapter has an offset of 25 mm along the Y axis and 25 mm along the Z axis.
Generation date: 2025-09-22
3D Model Round-to-Rectangular Tube Adapter STL file ⌀100 mm to 120×40 mm, thickness 2 mm + offset

3D model download

Free
  • round-to-rectangular-adapter-d_model1938-nb0_dd{id}.stl : 1.8 Mo
STL Mesh quality : Linear deflection 0.0005 Angular deflection 0.05
No compliance warranty No compliance warranty
(Internal and private use, non-commercial – no distribution – no derivatives)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Round to rectangular adapter template, with the following values:
Parameter Value
#1 cylinder outer diameter 100 mm (≃3 15/16 in)
#2 cylinder inlet length 35 mm (≃1 3/8 in)
#3 rectangle internal length 120 mm (≃4.72 in)
#4 rectangle internal height 40 mm (≃1 9/16 in)
#5 rectangle inlet length 75 mm (≃2 15/16 in)
#6 offset Z 25 mm (≃0.98 in)
#7 offset Y 25 mm (≃0.98 in)
#8 total length 175 mm (≃6 7/8 in)
#9 thickness 2 mm (≃0.08 in)
#10 chamfer no chamfer
Metadata Value
Cylinder internal diameter 96 mm (≃3.78 in)
illustration of the parameters
Parameter overview

  • If the chamfer option on the ends is enabled, the chamfer length is equal to half the thickness.
  • The stop at the bottom of the rectangular section has a width equal to half the thickness.

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 cylinder outer diameter diaC
#2 cylinder inlet length lentC
#3 rectangle internal length lenIR
#4 rectangle internal height heiIR
#5 rectangle inlet length lentR
#6 offset Z ofsZ
#7 offset Y ofsY
#8 total length lenT
#9 thickness thi
#10 chamfer cha

Related 3D models

To search for a model based on your own parameters, go to the template page Round to rectangular adapter

Round-to-Rectangular Tube Adapter STL 3D file ⌀100 mm to 135×75 mm, thickness 2 mm + offset (📦 #1975)

1 object(s) - format STL
Round-to-Rectangular Tube Adapter STL 3D file ⌀100 mm to 135×75 mm, thickness 2 mm + offset
File in STL format of a round-to-rectangular tube adapter with an external diameter of ⌀100 mm and a rectangular section with internal dimensions 135×75 mm. The shell thickness is 2 mm and the overall length is 160 mm. The adapter has an offset of 30 mm along the Y axis and 30 mm along the Z axis.
Parameter Value Unit
cylinder outer diameter 100 mm
cylinder inlet length 35 mm
rectangle internal length 135 mm
rectangle internal height 75 mm
rectangle inlet length 60 mm
offset Z 30 mm
offset Y 30 mm
total length 160 mm
thickness 2 mm
chamfer no chamfer
