Values for this model

This model was generated by the Round to rectangular adapter template, with the following values:
Parameter Value
#1 cylinder outer diameter 120 mm (≃4.72 in)
#2 cylinder inlet length 5 mm (≃3/16 in)
#3 rectangle internal length 250 mm (≃9.84 in)
#4 rectangle internal height 50 mm (≃1.97 in)
#5 rectangle inlet length 60 mm (≃2 3/8 in)
#6 offset Z 10 mm (≃0.39 in)
#7 offset Y 30 mm (≃1 3/16 in)
#8 total length 165 mm (≃6 1/2 in)
#9 thickness 2 mm (≃0.08 in)
#10 chamfer no chamfer
Metadata Value
Cylinder internal diameter 116 mm (≃4 9/16 in)
illustration of the parameters
Parameter overview

  • If the chamfer option on the ends is enabled, the chamfer length is equal to half the thickness.
  • The stop at the bottom of the rectangular section has a width equal to half the thickness.

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 cylinder outer diameter diaC
#2 cylinder inlet length lentC
#3 rectangle internal length lenIR
#4 rectangle internal height heiIR
#5 rectangle inlet length lentR
#6 offset Z ofsZ
#7 offset Y ofsY
#8 total length lenT
#9 thickness thi
#10 chamfer cha
