Custom Round-to-Rectangular Tube Adapter STL file ⌀106 mm to 92.6×71 mm, thickness 2 mm + offset 📦#3315

STL Download STL 1
Create a new model:
from scratch search for a model
Model in STL format of a round-to-rectangular tube adapter with an outer diameter of ⌀106 mm and a rectangular section with internal dimensions 92.6×71 mm. The shell thickness is 2 mm and the overall length is 170 mm. The adapter has an offset of 25 mm along the Z axis.
Generation date: 2025-11-16
3D Model Round-to-Rectangular Tube Adapter STL file ⌀106 mm to 92.6×71 mm, thickness 2 mm + offset

3D model download

Free
  • round-to-rectangular-adapter-d_model3315-nb0_dd{id}.stl : 1.6 Mo
STL Mesh quality : Linear deflection 0.0005 Angular deflection 0.05
No compliance warranty No compliance warranty
(Internal and private use, non-commercial – no distribution – no derivatives)
Safe download

Values for this model

This model was generated by the Round to rectangular adapter template, with the following values:
Parameter Value
#1 cylinder outer diameter 106 mm (≃4 3/16 in)
#2 cylinder inlet length 50 mm (≃1.97 in)
#3 rectangle internal length 92.6 mm (≃3.65 in)
#4 rectangle internal height 71 mm (≃2.80 in)
#5 rectangle inlet length 70 mm (≃2 3/4 in)
#6 offset Z 25 mm (≃0.98 in)
#7 offset Y 0 mm (0 in)
#8 total length 170 mm (≃6 11/16 in)
#9 thickness 2 mm (≃0.08 in)
#10 chamfer no chamfer
Metadata Value
Cylinder internal diameter 102 mm (≃4.02 in)
illustration of the parameters
Parameter overview

  • If the chamfer option on the ends is enabled, the chamfer length is equal to half the thickness.
  • The stop at the bottom of the rectangular section has a width equal to half the thickness.

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 cylinder outer diameter diaC
#2 cylinder inlet length lentC
#3 rectangle internal length lenIR
#4 rectangle internal height heiIR
#5 rectangle inlet length lentR
#6 offset Z ofsZ
#7 offset Y ofsY
#8 total length lenT
#9 thickness thi
#10 chamfer cha
