Straight tube adapter ⌀180 mm to ⌀16 mm in STL format. Final length of this fitting is 150 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 50 mm, the smaller one of 30 mm. The ends are not rounded.
Generation date: 2025-08-25
3D Model Tube adapter STL file ⌀ 180–16 mm (Length: 150 mm)

3D model download

Free
  • inline-tube-adapter-lenA50mm-d_model1423-nb0_dd{id}.stl : 9.8 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 50 mm (≃1.97 in)
#2 side A outer diameter 180 mm (≃7.09 in)
#3 side A thickness 3 mm (≃1/8 in)
#4 side B length 30 mm (≃1 3/16 in)
#5 side B outer diameter 16 mm (≃5/8 in)
#6 side B thickness 3 mm (≃1/8 in)
#7 transition length 70 mm (≃2 3/4 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 174 mm (≃6.85 in)
inner diameter (side B) 10 mm (≃0.39 in)
total length 150 mm (≃5.91 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
