Tube adapter ⌀ 180–60 mm (Length: 150 mm) 📦#1424
Generation date: 2025-08-25
3D model download
Free- inline-tube-adapter-lenA50mm-d_model1424-nb0_dd{id}.stl : 3.5 Mo
STL
Mesh quality :
0.05
0.05
License: CC BY - Creative commons
(attribution - commercial use allowed)
Values for this model
This model was generated by the Inline tube adapter template, with the following values:
| Template parameter | Value | Unit | Label | |
|---|---|---|---|---|
| #1 | side A length | 50 | mm | lenA |
| #2 | side A outer diameter | 180 | mm | diA |
| #3 | side A thickness | 3 | mm | thA |
| #4 | side B length | 30 | mm | lenB |
| #5 | side B outer diameter | 60 | mm | diB |
| #6 | side B thickness | 3 | mm | thB |
| #7 | transition length | 70 | mm | tra |
| #8 | axis offset | 0 | mm | ofs |
| #9 | ends fillet | 0 | 0,1,2,3 | fil |
Representation of the parameters
The transition refers to the connection interface between the two tubes. It defines the total length of the adapter, which is equal to the sum of the tube lengths plus the length of the transition.
Details for parameter #9 ends fillet:
- 0: no fillet
- 1: fillet on the outside
- 2: fillet on the inside
- 3: fillet on both inside and outside
