Custom Tube adapter STL 3D file ⌀ 69–65 mm (Length: 100 mm) 📦#1393

STL Download STL 1
Create a new model:
from scratch search for a model
Inline tube coupler ⌀69 mm to ⌀65 mm in STL format. Final length of this fitting is 100 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 40 mm, the smaller one of 50 mm. The ends feature an external fillet to make tube connection easier.
Generation date: 2025-08-21
3D Model Tube adapter STL 3D file ⌀ 69–65 mm (Length: 100 mm)

3D model download

Free
  • inline-tube-adapter-lenA40mm-d_model1393-nb0_dd{id}.stl : 3.7 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 40 mm (≃1 9/16 in)
#2 side A outer diameter 69 mm (≃2.72 in)
#3 side A thickness 2 mm (≃0.08 in)
#4 side B length 50 mm (≃1.97 in)
#5 side B outer diameter 65 mm (≃2 9/16 in)
#6 side B thickness 2 mm (≃0.08 in)
#7 transition length 10 mm (≃0.39 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet fillet on the outside
Metadata Value
inner diameter (side A) 65 mm (≃2 9/16 in)
inner diameter (side B) 61 mm (≃2.40 in)
total length 100 mm (≃3 15/16 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
