Tube adapter ⌀ 80–75 mm (Length: 101 mm) 📦#1219

Name: STL 3D File Tube adapter ⌀ 80–75 mm (Length: 101 mm) #1219
Brand: iteration3d
SKU: 1219
Availability: InStock

STL Download STL

Diameter adapter ⌀80 mm to ⌀75 mm in STL format. Final length of this adapter is 101 mm. The thickness of the tubes is identical: 2.5 mm. The axes of the tubes are offset. The ends are rounded on the outside to facilitate the connection of the two tubes.

Generation date: 2025-07-19

3D Model Tube adapter ⌀ 80–75 mm (Length: 101 mm)

3D model download

Free

Download format: zip : 4.9 Mo (1 file(s))

inline-tube-adapter-lenA46mm-d_model1219-nb0_dd{id}.stl : 4.9 Mo

STL Mesh quality : not defined

License: CC BY - Creative commons

(attribution - commercial use allowed)

Values for this model

This model was generated by the Inline tube adapter template, with the following values:

	Parameter	Value
#1	side A length	46 mm
#2	side A outer diameter	80 mm
#3	side A thickness	2.5 mm
#4	side B length	45 mm
#5	side B outer diameter	75 mm
#6	side B thickness	2.5 mm
#7	transition length	10 mm
#8	axis offset	2.4 mm
#9	ends fillet	fillet on the outside

Representation of the parameters

Labels are used in the naming of the downloaded 3D files.

Parameter	Label
#1 side A length	lenA
#2 side A outer diameter	diA
#3 side A thickness	thA
#4 side B length	lenB
#5 side B outer diameter	diB
#6 side B thickness	thB
#7 transition length	tra
#8 axis offset	ofs
#9 ends fillet	fil
