Inline fitting ⌀56 mm to ⌀50 mm in STL format. Length of this adapter is 120 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 50 mm, the smaller one of 50 mm as well. The ends have no fillet.
Generation date: 2025-08-31
3D Model Tube adapter STL 3D file ⌀ 56–50 mm (Length: 120 mm)

3D model download

Free
  • inline-tube-adapter-lenA50mm-d_model1493-nb0_dd{id}.stl : 695 Ko
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 50 mm
#2 side A outer diameter 56 mm
#3 side A thickness 2 mm
#4 side B length 50 mm
#5 side B outer diameter 50 mm
#6 side B thickness 2 mm
#7 transition length 20 mm
#8 axis offset 0 mm
#9 ends fillet no fillet
illustration of the parameters
Representation of the parameters

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
