Inline tube adapter 3D Files - Side A outer diameter 100 to 150 mm | page 6

Straight tube coupler ⌀110 mm to ⌀80 mm in STL format. Total length of this reducer is 58 mm. The thickness of the tubes is identical: 4 mm. The larger-diameter tube has a sleeve length of 20 mm, the smaller one of 25 mm. The ends have a fillet on the outside.

Tube reducer ⌀110 mm to ⌀80 mm in STL format. Final length of this sleeve is 78 mm. The larger-diameter tube has a thickness of 4 mm and a sleeve length of 25 mm. The smaller-diameter tube has a thickness of 2 mm and a length of 40 mm. The ends have no fillet.

Tubing adapter ⌀110 mm to ⌀90 mm in STL 3D format. Total length of this adapter is 70 mm. The thickness of the tubes is identical: 10 mm. The larger-diameter tube has a sleeve length of 20 mm, the smaller one of 30 mm. The ends are not rounded.

Tubing adapter ⌀110 mm to ⌀90 mm in STL format. Final length of this sleeve is 130 mm. The thickness of the tubes is identical: 10 mm. The larger-diameter tube has a sleeve length of 20 mm, the smaller one of 100 mm. The ends are not rounded.

Tube junction ⌀110 mm to ⌀98 mm in STL format. Total length of this junction is 70 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a sleeve length of 20 mm, the smaller one of 30 mm. The ends have no fillet.

Inline sleeve ⌀110 mm to ⌀85 mm in STL format. Length of this reducer is 175 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 25 mm, the smaller one of 50 mm. The ends have a fillet to make tube connection easier.

Inline tube reducer ⌀110 mm to ⌀85 mm in STL format. Total length of this connector is 97 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a length of 12 mm, the smaller one of 25 mm. The ends have a fillet to facilitate the connection of the two tubes.

Tube adapter ⌀110 mm to ⌀80 mm in STL format. Final length of this connector is 85 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a length of 15 mm, the smaller one of 20 mm. The ends have a fillet to facilitate the connection of the two tubes.

Inline tube junction ⌀110 mm to ⌀100 mm in STL 3D format. Final length of this reducer is 110 mm. The larger-diameter tube has a thickness of 6 mm and a sleeve length of 35 mm. The smaller-diameter tube has a thickness of 5 mm and a length of 35 mm as well. The ends have no fillet.

Inline tube coupler ⌀110 mm to ⌀75 mm in STL format. Length of this reducer is 110 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 30 mm, the smaller one of 30 mm as well. The ends are not rounded.

Inline tube reducer ⌀110 mm to ⌀75 mm in STL 3D format. Length of this junction is 90 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 30 mm, the smaller one of 30 mm as well. The ends are raw.

Tubing reducer ⌀110 mm to ⌀93 mm in STL 3D format. Final length of this coupler is 50 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 20 mm, the smaller one of 20 mm as well. The ends are raw.

Inline sleeve ⌀110 mm to ⌀94 mm in STL format. Length of this junction is 45 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 15 mm, the smaller one of 15 mm as well. The ends are not rounded.

Straight tube reducer ⌀110 mm to ⌀80 mm in STL 3D format. Final length of this adapter is 100 mm. The thickness of the tubes is identical: 4 mm. The larger-diameter tube has a length of 40 mm, the smaller one of 50 mm. The ends have no fillet.

Inline tube adapter ⌀110 mm to ⌀80 mm in STL 3D format. Length of this coupler is 85 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a length of 15 mm, the smaller one of 20 mm. The two axes of the tubes are offset by 2 mm. The ends feature a fillet to facilitate the connection of the two tubes.

Tube junction ⌀110 mm to ⌀95 mm in STL format. Total length of this sleeve is 110 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a sleeve length of 30 mm, the smaller one of 30 mm as well. The ends have a fillet on the outside.

Inline tube junction ⌀110 mm to ⌀95 mm in STL 3D format. Total length of this adapter is 81 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a length of 30 mm, the smaller one of 30 mm as well. The ends have a fillet on the outside to ease the connection.

Inline tube adapter ⌀110 mm to ⌀108 mm in STL 3D format. Total length of this connector is 80 mm. The thickness of the tubes is identical: 4 mm. The larger-diameter tube has a length of 30 mm, the smaller one of 30 mm as well. The ends are rounded on the outside to ease the connection.

Straight sleeve ⌀110 mm to ⌀88 mm in STL format. Length of this adapter is 150 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 50 mm, the smaller one of 50 mm as well. The ends feature an internal fillet to facilitate the connection of the two tubes.

Tube adapter ⌀110 mm to ⌀75 mm in STL format. Total length of this junction is 205 mm. The larger-diameter tube has a thickness of 5 mm and a length of 100 mm. The smaller-diameter tube has a thickness of 4 mm and a length of 100 mm as well. The ends are raw.

Straight tubing adapter ⌀110 mm to ⌀95 mm in STL 3D format. Final length of this adapter is 110 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a length of 35 mm, the smaller one of 35 mm as well. The ends feature an internal fillet to make tube connection easier.

Tube coupler ⌀110 mm to ⌀100 mm in STL format. Length of this sleeve is 120 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a sleeve length of 40 mm, the smaller one of 40 mm as well. The ends are raw.

Tube connector ⌀111 mm to ⌀90 mm in STL format. Final length of this adapter is 170 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a sleeve length of 70 mm, the smaller one of 80 mm. The ends have a fillet on the outside to ease the connection.

Inline tube reducer ⌀111 mm to ⌀100 mm in STL format. Length of this connector is 180 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a length of 80 mm, the smaller one of 80 mm as well. The ends feature an external fillet to facilitate the connection of the two tubes.

Straight tubing adapter ⌀111 mm to ⌀56 mm in STL format. Total length of this coupler is 160 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 50 mm, the smaller one of 70 mm. The ends are raw.

Straight sleeve ⌀111 mm to ⌀79 mm in STL 3D format. Length of this fitting is 85 mm. The larger-diameter tube has a thickness of 3 mm and a length of 25 mm. The smaller-diameter tube has a thickness of 2 mm and a length of 20 mm. The two axes of the tubes are off-center by 14.9 mm. The ends feature an external fillet to make tube connection easier.

Inline tube coupler ⌀112 mm to ⌀75 mm in STL 3D format. Length of this junction is 80 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 25 mm, the smaller one of 25 mm as well. The ends have no fillet.

Straight tube coupler ⌀112 mm to ⌀110 mm in STL format. Length of this junction is 80 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a length of 30 mm, the smaller one of 30 mm as well. The ends are rounded on the outside to ease the connection.

Straight tube reducer ⌀113 mm to ⌀40 mm in STL format. Length of this coupler is 65 mm. The larger-diameter tube has a thickness of 3 mm and a length of 25 mm. The smaller-diameter tube has a thickness of 18 mm and a length of 20 mm. The ends have no fillet.

Tube fitting ⌀113 mm to ⌀40 mm in STL 3D format. Final length of this reducer is 65 mm. The larger-diameter tube has a thickness of 3 mm and a length of 25 mm. The smaller-diameter tube has a thickness of 18 mm and a length of 20 mm. The axes of the tubes are offset by 37 mm. The ends are not rounded.
