Tube adapter ⌀ 110–100 mm (Length: 270 mm) 📦#1477
Generation date: 2025-08-30
3D model download
Free- inline-tube-adapter-lenA150mm-_model1477-nb0_dd{id}.stl : 4.3 Mo
STL
Mesh quality :
0.05
0.05
License: CC BY - Creative commons
(attribution - commercial use allowed)
Values for this model
This model was generated by the Inline tube adapter template, with the following values:
| Template parameter | Value | Unit | Label | |
|---|---|---|---|---|
| #1 | side A length | 150 | mm | lenA |
| #2 | side A outer diameter | 110 | mm | diA |
| #3 | side A thickness | 5 | mm | thA |
| #4 | side B length | 100 | mm | lenB |
| #5 | side B outer diameter | 100 | mm | diB |
| #6 | side B thickness | 5 | mm | thB |
| #7 | transition length | 20 | mm | tra |
| #8 | axis offset | 0 | mm | ofs |
| #9 | ends fillet | 1 | fil | |
