Custom Tube adapter STL file ⌀ 27–23 mm (Length: 192 mm) 📦#3896

STL Download STL 1
Create a new model:
from scratch search for a model
Tube junction ⌀27 mm to ⌀23 mm in STL format. Length of this fitting is 192 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 61 mm, the smaller one of 71 mm. The ends are raw.
Generation date: 2025-11-27
3D Model Tube adapter STL file ⌀ 27–23 mm (Length: 192 mm)

3D model download

Free
  • inline-tube-adapter-lenA61mm-d_model3896-nb0_dd{id}.stl : 775.3 Ko
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 61 mm (≃2.40 in)
#2 side A outer diameter 27 mm (≃1 1/16 in)
#3 side A thickness 2 mm (≃0.08 in)
#4 side B length 71 mm (≃2.80 in)
#5 side B outer diameter 23 mm (≃0.91 in)
#6 side B thickness 2 mm (≃0.08 in)
#7 transition length 60 mm (≃2 3/8 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 23 mm (≃0.91 in)
inner diameter (side B) 19 mm (≃3/4 in)
total length 192 mm (≃7 9/16 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
