Custom Tube adapter STL 3D file ⌀ 68–39 mm (Length: 130 mm) 📦#3348

STL Download STL 2
Create a new model expert
from scratch search for a model
Inline tubing adapter ⌀68 mm to ⌀39 mm in STL 3D format. Final length of this reducer is 130 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 35 mm, the smaller one of 70 mm. The ends are rounded on the inside to ease the connection.
Generation date: 2025-11-16
3D Model Tube adapter STL 3D file ⌀ 68–39 mm (Length: 130 mm)

3D model download

Free
  • inline-tube-adapter-lenA35mm-d_model3348-nb0_dd{id}.stl : 6.3 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 35 mm (≃1 3/8 in)
#2 side A outer diameter 68 mm (≃2 11/16 in)
#3 side A thickness 2 mm (≃0.08 in)
#4 side B length 70 mm (≃2 3/4 in)
#5 side B outer diameter 39 mm (≃1.54 in)
#6 side B thickness 2 mm (≃0.08 in)
#7 transition length 25 mm (≃0.98 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet fillet on the inside
Metadata Value
inner diameter (side A) 64 mm (≃2.52 in)
inner diameter (side B) 35 mm (≃1 3/8 in)
total length 130 mm (≃5 1/8 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
