Tube adapter STL file ⌀ 200–140 mm (Length: 180 mm) 📦#2220

STL Download STL
Create a new model:
from scratch search for a model
Tube connector ⌀200 mm to ⌀140 mm in STL format. Final length of this coupler is 180 mm. The thickness of the tubes is identical: 7 mm. The larger-diameter tube has a sleeve length of 60 mm, the smaller one of 60 mm as well. The ends are raw.
Generation date: 2025-10-05
3D Model Tube adapter STL file ⌀ 200–140 mm (Length: 180 mm)

3D model download

Free
  • inline-tube-adapter-lenA60mm-d_model2220-nb0_dd{id}.stl : 4.5 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 60 mm
#2 side A outer diameter 200 mm
#3 side A thickness 7 mm
#4 side B length 60 mm
#5 side B outer diameter 140 mm
#6 side B thickness 7 mm
#7 transition length 60 mm
#8 axis offset 0 mm
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 186 mm
inner diameter (side B) 126 mm
total length 180 mm
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
