Tube fitting ⌀100 mm to ⌀50 mm in STL format. Total length of this sleeve is 90 mm. The larger-diameter tube has a thickness of 2 mm and a sleeve length of 30 mm. The smaller-diameter tube has a thickness of 20 mm and a length of 30 mm as well. The two axes of the tubes are off-center by 25.4 mm. The ends are rounded on the inside to ease the connection.
Generation date: 2025-08-27
3D Model Tube adapter STL 3D file ⌀ 100–50 mm (Length: 90 mm)

3D model download

Free
  • inline-tube-adapter-lenA30mm-d_model1453-nb0_dd{id}.stl : 6.7 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 30 mm (≃1 3/16 in)
#2 side A outer diameter 100 mm (≃3 15/16 in)
#3 side A thickness 2 mm (≃0.08 in)
#4 side B length 30 mm (≃1 3/16 in)
#5 side B outer diameter 50 mm (≃1.97 in)
#6 side B thickness 20 mm (≃0.79 in)
#7 transition length 30 mm (≃1 3/16 in)
#8 axis offset 25.4 mm (1 in)
#9 ends fillet fillet on the inside
Metadata Value
inner diameter (side A) 96 mm (≃3.78 in)
inner diameter (side B) 10 mm (≃0.39 in)
total length 90 mm (≃3.54 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
