Inline tube adapter 3D Files - Side A outer diameter 100 to 150 mm | page 3

Tube fitting ⌀108 mm to ⌀93 mm in STL format. Length of this sleeve is 190 mm. The thickness of the tubes is identical: 4 mm. The larger-diameter tube has a length of 100 mm, the smaller one of 75 mm. The two axes of the tubes are offset by 7.4 mm. The ends have no fillet.

Tube adapter ⌀110 mm to ⌀106 mm in STL format. Final length of this junction is 35 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a length of 20 mm, the smaller one of 10 mm. The ends have no fillet.

Diameter adapter ⌀110 mm to ⌀100 mm in STL format. Final length of this sleeve is 270 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a length of 150 mm, the smaller one of 100 mm. The ends have a fillet on the outside.

Tube coupler ⌀110 mm to ⌀90 mm in STL 3D format. Length of this connector is 215 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a sleeve length of 100 mm, the smaller one of 100 mm as well. The ends are rounded on the outside.

Inline tube coupler ⌀110 mm to ⌀100 mm in STL 3D format. Final length of this fitting is 225 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a sleeve length of 110 mm, the smaller one of 100 mm. The ends have a fillet on the outside.

Straight tube coupler ⌀110 mm to ⌀40 mm in STL 3D format. Final length of this connector is 215 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a sleeve length of 100 mm, the smaller one of 100 mm as well. The ends are rounded to ease the connection.

Tube coupler ⌀110 mm to ⌀100 mm in STL format. Final length of this adapter is 35 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 20 mm, the smaller one of 10 mm. The ends are raw.

Straight tube connector ⌀110 mm to ⌀100 mm in STL format. Total length of this coupler is 125 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 50 mm, the smaller one of 70 mm. The ends are not rounded.

Diameter adapter ⌀110 mm to ⌀100 mm in STL format. Length of this fitting is 35 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 20 mm, the smaller one of 10 mm. The ends are rounded on the outside to ease the connection.

Straight sleeve ⌀110 mm to ⌀80 mm in STL 3D format. Total length of this adapter is 63 mm. The thickness of the tubes is identical: 4 mm. The larger-diameter tube has a length of 25 mm, the smaller one of 25 mm as well. The ends are not rounded.

Straight tube reducer ⌀110 mm to ⌀80 mm in STL format. Final length of this connector is 63 mm. The thickness of the tubes is identical: 4 mm. The larger-diameter tube has a length of 25 mm, the smaller one of 25 mm as well. The ends feature an external fillet to ease the connection.

Straight tube coupler ⌀110 mm to ⌀80 mm in STL format. Total length of this reducer is 58 mm. The thickness of the tubes is identical: 4 mm. The larger-diameter tube has a sleeve length of 20 mm, the smaller one of 25 mm. The ends have a fillet on the outside.

Tube reducer ⌀110 mm to ⌀80 mm in STL format. Final length of this sleeve is 78 mm. The larger-diameter tube has a thickness of 4 mm and a sleeve length of 25 mm. The smaller-diameter tube has a thickness of 2 mm and a length of 40 mm. The ends have no fillet.

Tubing adapter ⌀110 mm to ⌀90 mm in STL 3D format. Total length of this adapter is 70 mm. The thickness of the tubes is identical: 10 mm. The larger-diameter tube has a sleeve length of 20 mm, the smaller one of 30 mm. The ends are not rounded.

Tubing adapter ⌀110 mm to ⌀90 mm in STL format. Final length of this sleeve is 130 mm. The thickness of the tubes is identical: 10 mm. The larger-diameter tube has a sleeve length of 20 mm, the smaller one of 100 mm. The ends are not rounded.

Tube junction ⌀110 mm to ⌀98 mm in STL format. Total length of this junction is 70 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a sleeve length of 20 mm, the smaller one of 30 mm. The ends have no fillet.

Tube connector ⌀111 mm to ⌀90 mm in STL format. Final length of this adapter is 170 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a sleeve length of 70 mm, the smaller one of 80 mm. The ends have a fillet on the outside to ease the connection.

Inline tube reducer ⌀111 mm to ⌀100 mm in STL format. Length of this connector is 180 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a length of 80 mm, the smaller one of 80 mm as well. The ends feature an external fillet to facilitate the connection of the two tubes.

Straight tube reducer ⌀113 mm to ⌀40 mm in STL format. Length of this coupler is 65 mm. The larger-diameter tube has a thickness of 3 mm and a length of 25 mm. The smaller-diameter tube has a thickness of 18 mm and a length of 20 mm. The ends have no fillet.

Tube fitting ⌀113 mm to ⌀40 mm in STL 3D format. Final length of this reducer is 65 mm. The larger-diameter tube has a thickness of 3 mm and a length of 25 mm. The smaller-diameter tube has a thickness of 18 mm and a length of 20 mm. The axes of the tubes are offset by 37 mm. The ends are not rounded.

Tube junction ⌀113 mm to ⌀40 mm in STL format. Final length of this coupler is 85 mm. The larger-diameter tube has a thickness of 3 mm and a sleeve length of 25 mm. The smaller-diameter tube has a thickness of 18 mm and a length of 20 mm. The ends are raw.

Tube junction ⌀113 mm to ⌀40 mm in STL format. Total length of this reducer is 85 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 25 mm, the smaller one of 20 mm. The ends have no fillet.

Inline fitting ⌀115 mm to ⌀105 mm in STL 3D format. Final length of this fitting is 120 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a sleeve length of 50 mm, the smaller one of 50 mm as well. The axes of the tubes are off-center by 4.9 mm. The ends feature a fillet to facilitate the connection of the two tubes.

Inline tube adapter ⌀115 mm to ⌀100 mm in STL format. Total length of this sleeve is 65 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 30 mm, the smaller one of 30 mm as well. The ends have no fillet.

Inline tubing adapter ⌀115 mm to ⌀65 mm in STL format. Length of this fitting is 100 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a sleeve length of 30 mm, the smaller one of 40 mm. The ends are rounded on the outside.

Straight tube fitting ⌀115 mm to ⌀62 mm in STL format. Length of this fitting is 100 mm. The thickness of the tubes is identical: 2 mm. The larger-diameter tube has a length of 30 mm, the smaller one of 40 mm. The ends are rounded on the outside to ease the connection.

Tube adapter ⌀116 mm to ⌀100 mm in STL 3D format. Length of this junction is 113 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 50 mm, the smaller one of 50 mm as well. The ends are not rounded.

Straight tube fitting ⌀116 mm to ⌀100 mm in STL format. Final length of this reducer is 90 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 30 mm, the smaller one of 30 mm as well. The ends are not rounded.

Tube adapter ⌀117 mm to ⌀103 mm in STL 3D format. Length of this coupler is 90 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a length of 40 mm, the smaller one of 40 mm as well. The ends have a fillet to make tube connection easier.

Inline tube junction ⌀120 mm to ⌀90 mm in STL 3D format. Total length of this fitting is 75 mm. The larger-diameter tube has a thickness of 4 mm and a length of 25 mm. The smaller-diameter tube has a thickness of 3 mm and a length of 30 mm. The ends have a fillet on the outside to make tube connection easier.
