Tube junction ⌀102 mm to ⌀58 mm in STL format. Length of this sleeve is 105 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a sleeve length of 50 mm, the smaller one of 50 mm as well. The ends have no fillet.
Generation date: 2026-05-10
3D Model Tubing adapter STL 3D file ⌀ 102–58 mm (Length: 105 mm)

3D model download

Free
  • inline-tube-adapter-lenA50mm-d_model8877-nb0_dd{id}.stl : 6.8 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 50 mm (≃1.97 in)
#2 side A outer diameter 102 mm (≃4.02 in)
#3 side A thickness 3 mm (≃1/8 in)
#4 side B length 50 mm (≃1.97 in)
#5 side B outer diameter 58 mm (≃2.28 in)
#6 side B thickness 3 mm (≃1/8 in)
#7 transition length 5 mm (≃3/16 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 96 mm (≃3.78 in)
inner diameter (side B) 52 mm (≃2 1/16 in)
total length 105 mm (≃4 1/8 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
