Tube junction ⌀104 mm to ⌀90 mm in STL 3D format. Final length of this reducer is 80 mm. The thickness of the tubes is identical: 4 mm. The larger-diameter tube has a sleeve length of 25 mm, the smaller one of 30 mm. The ends are not rounded.
Generation date: 2025-11-13
3D Model Tubing adapter STL file ⌀ 104–90 mm (Length: 80 mm)

3D model download

Free
  • inline-tube-adapter-lenA25mm-d_model3258-nb0_dd{id}.stl : 1.4 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 25 mm (≃0.98 in)
#2 side A outer diameter 104 mm (≃4.09 in)
#3 side A thickness 4 mm (≃0.16 in)
#4 side B length 30 mm (≃1 3/16 in)
#5 side B outer diameter 90 mm (≃3.54 in)
#6 side B thickness 4 mm (≃0.16 in)
#7 transition length 25 mm (≃0.98 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet no fillet
Metadata Value
inner diameter (side A) 96 mm (≃3.78 in)
inner diameter (side B) 82 mm (≃3.23 in)
total length 80 mm (≃3.15 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
