Tubing adapter STL 3D file ⌀ 165–154 mm (Length: 78 mm) 📦#2662

STL Download STL
Create a new model:
from scratch search for a model
Diameter adapter ⌀165 mm to ⌀154 mm in STL 3D format. Final length of this reducer is 78 mm. The thickness of the tubes is identical: 2.4 mm. The larger-diameter tube has a sleeve length of 40 mm, the smaller one of 30 mm. The ends are raw.
Generation date: 2025-10-22
3D Model Tubing adapter STL 3D file ⌀ 165–154 mm (Length: 78 mm)

3D model download

Free
  • inline-tube-adapter-lenA40mm-d_model2662-nb0_dd{id}.stl : 5.3 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 40 mm
#2 side A outer diameter 165 mm
#3 side A thickness 2.4 mm
#4 side B length 30 mm
#5 side B outer diameter 154 mm
#6 side B thickness 2.4 mm
#7 transition length 8 mm
#8 axis offset 0 mm
#9 ends fillet no fillet
illustration of the parameters
Representation of the parameters

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
