Custom Tube adapter STL file ⌀ 50–30 mm (Length: 95 mm) 📦#1314

STL Download STL 3
Create a new model expert
from scratch search for a model
Tube fitting ⌀50 mm to ⌀30 mm in STL format. Final length of this reducer is 95 mm. The larger-diameter tube has a thickness of 5 mm and a length of 30 mm. The smaller-diameter tube has a thickness of 3 mm and a length of 50 mm. The ends have a fillet to facilitate the connection of the two tubes.
Generation date: 2025-08-02
3D Model Tube adapter STL file ⌀ 50–30 mm (Length: 95 mm)

3D model download

Free
  • inline-tube-adapter-lenA30mm-d_model1314-nb0_dd{id}.stl : 8.3 Mo
STL Mesh quality : not defined
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 30 mm (≃1 3/16 in)
#2 side A outer diameter 50 mm (≃1.97 in)
#3 side A thickness 5 mm (≃3/16 in)
#4 side B length 50 mm (≃1.97 in)
#5 side B outer diameter 30 mm (≃1 3/16 in)
#6 side B thickness 3 mm (≃1/8 in)
#7 transition length 15 mm (≃0.59 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet fillet on both inside
and outside
Metadata Value
inner diameter (side A) 40 mm (≃1 9/16 in)
inner diameter (side B) 24 mm (≃15/16 in)
total length 95 mm (≃3 3/4 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
