Custom Tubing adapter STL 3D file ⌀ 40–37 mm (Length: 115 mm) 📦#4476

STL Download STL 3
Create a new model expert
from scratch search for a model
Tube adapter ⌀40 mm to ⌀37 mm in STL 3D format. Length of this connector is 115 mm. The thickness of the tubes is identical: 5 mm. The larger-diameter tube has a sleeve length of 35 mm, the smaller one of 40 mm. The ends are rounded to facilitate the connection of the two tubes.
Generation date: 2025-12-09
3D Model Tubing adapter STL 3D file ⌀ 40–37 mm (Length: 115 mm)

3D model download

Free
  • inline-tube-adapter-lenA35mm-d_model4476-nb0_dd{id}.stl : 6.6 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 35 mm (≃1 3/8 in)
#2 side A outer diameter 40 mm (≃1 9/16 in)
#3 side A thickness 5 mm (≃3/16 in)
#4 side B length 40 mm (≃1 9/16 in)
#5 side B outer diameter 37 mm (≃1.46 in)
#6 side B thickness 5 mm (≃3/16 in)
#7 transition length 40 mm (≃1 9/16 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet fillet on both inside
and outside
Metadata Value
inner diameter (side A) 30 mm (≃1 3/16 in)
inner diameter (side B) 27 mm (≃1 1/16 in)
total length 115 mm (≃4.53 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
