Pipe elbow 3D Files - Outer diameter 200 mm and over

10 Model(s)

Tube elbow STL 3D file 57° ⌀OD: 200 mm ⌀ID: 198 mm thickness: 1 mm (📦 #7162)

1 object(s) - format STL
Tube elbow STL 3D file 57° ⌀OD: 200 mm ⌀ID: 198 mm thickness: 1 mm
3D model of a tubing elbow with a 57° angle in STL format. This pipe elbow features an external diameter of 200 mm and an internal diameter of 198 mm. The tube thickness is therefore 1 mm. The ends feature fillets to make it easier to assemble.
Parameter Value Unit
outer diameter 200 mm
inner diameter 198 mm
angle 57 °
end fillets yes

Tube elbow STL 3D file 90° ⌀OD: 200 mm ⌀ID: 196 mm thickness: 2 mm (📦 #8010)

1 object(s) - format STL
Tube elbow STL 3D file 90° ⌀OD: 200 mm ⌀ID: 196 mm thickness: 2 mm
File of an elbow with a 90° angle in STL format. This pipe elbow features an outer diameter of 200 mm and an inner diameter of 196 mm. The tube thickness is therefore 2 mm.
Parameter Value Unit
outer diameter 200 mm
inner diameter 196 mm
angle 90 °
end fillets no

Tubing elbow STL file 90° ⌀OD: 200 mm ⌀ID: 198.2 mm thickness: 0.90000000000001 mm (📦 #8075)

1 object(s) - format STL
Tubing elbow STL file 90° ⌀OD: 200 mm ⌀ID: 198.2 mm thickness: 0.90000000000001 mm
3D model of a tubing elbow with a 90° angle in STL format. This elbow has an outer diameter of 200 mm and an inner diameter of 198.2 mm. The tube thickness is therefore 0.90000000000001 mm. The ends feature fillets to make it easier to insert.
Parameter Value Unit
outer diameter 200 mm
inner diameter 198.2 mm
angle 90 °
end fillets yes

Tube elbow STL file 90° ⌀OD: 210 mm ⌀ID: 160 mm thickness: 25 mm (📦 #3287)

1 object(s) - format STL
Tube elbow STL file 90° ⌀OD: 210 mm ⌀ID: 160 mm thickness: 25 mm
3D model of a pipe elbow with a 90° angle in STL format. This elbow features an external diameter of 210 mm and an internal diameter of 160 mm. This results in a tube thickness of 25 mm.
Parameter Value Unit
outer diameter 210 mm
inner diameter 160 mm
angle 90 °
end fillets no

Pipe elbow STL file 90° ⌀OD: 210 mm ⌀ID: 200 mm thickness: 5 mm (📦 #5390)

1 object(s) - format STL
Pipe elbow STL file 90° ⌀OD: 210 mm ⌀ID: 200 mm thickness: 5 mm
Model of an elbow with a 90° angle in STL format. This elbow features an external diameter of 210 mm and an internal diameter of 200 mm. This results in a tube thickness of 5 mm.
Parameter Value Unit
outer diameter 210 mm
inner diameter 200 mm
angle 90 °
end fillets no

Tube elbow STL file 45° ⌀OD: 230 mm ⌀ID: 210 mm thickness: 10 mm (📦 #7716)

1 object(s) - format STL
Tube elbow STL file 45° ⌀OD: 230 mm ⌀ID: 210 mm thickness: 10 mm
3D model of an elbow with a 45° angle in STL format. This elbow has an external diameter of 230 mm and an internal diameter of 210 mm. The tube thickness is therefore 10 mm.
Parameter Value Unit
outer diameter 230 mm
inner diameter 210 mm
angle 45 °
end fillets no

Pipe elbow STL file 90° ⌀OD: 250 mm ⌀ID: 240 mm thickness: 5 mm (📦 #1425)

1 object(s) - format STL
Pipe elbow STL file 90° ⌀OD: 250 mm ⌀ID: 240 mm thickness: 5 mm
File of an elbow with a 90° angle in STL format. This pipe elbow has an outer diameter of 250 mm and an inner diameter of 240 mm. The tube thickness is therefore 5 mm.
Parameter Value Unit
outer diameter 250 mm
inner diameter 240 mm
angle 90 °
end fillets no

Pipe elbow STL file 90° ⌀OD: 300 mm ⌀ID: 280 mm thickness: 10 mm (📦 #1611)

1 object(s) - format STL
Pipe elbow STL file 90° ⌀OD: 300 mm ⌀ID: 280 mm thickness: 10 mm
3D file of an elbow with a 90° angle in STL format. This elbow has an external diameter of 300 mm and an internal diameter of 280 mm. The tube thickness is therefore 10 mm.
Parameter Value Unit
outer diameter 300 mm
inner diameter 280 mm
angle 90 °
end fillets no

Pipe elbow STL 3D file 90° ⌀OD: 300 mm ⌀ID: 280 mm thickness: 10 mm (📦 #1612)

1 object(s) - format STL
Pipe elbow STL 3D file 90° ⌀OD: 300 mm ⌀ID: 280 mm thickness: 10 mm
Model of an elbow with a 90° angle in STL format. This pipe elbow features an outer diameter of 300 mm and an inner diameter of 280 mm. The tube thickness is therefore 10 mm. The ends feature fillets to make it easier to insert.
Parameter Value Unit
outer diameter 300 mm
inner diameter 280 mm
angle 90 °
end fillets yes

Tubing elbow STL 3D file 90° ⌀OD: 300 mm ⌀ID: 1 mm thickness: 149.5 mm (📦 #7035)

1 object(s) - format STL
Tubing elbow STL 3D file 90° ⌀OD: 300 mm ⌀ID: 1 mm thickness: 149.5 mm
3D file of an elbow with a 90° angle in STL format. This elbow features an external diameter of 300 mm and an internal diameter of 1 mm. This results in a tube thickness of 149.5 mm.
Parameter Value Unit
outer diameter 300 mm
inner diameter 1 mm
angle 90 °
end fillets no
Can't find the right model? Create it with your specs
