Custom Tubing adapter STL 3D file ⌀ 48–32 mm (Length: 75 mm) 📦#9506
Generation date: 2026-06-18
3D model download
Free- inline-tube-adapter-lenA25mm-d_model9506-nb0_dd{id}.stl : 1.1 Mo
STL
Mesh quality :
0.05
0.05
No compliance warranty
License: CC BY - Creative commons
(attribution - commercial use allowed)
Safe download
Values for this model
This model was generated by the Inline tube adapter template, with the following values:
| Parameter | Value | |
|---|---|---|
| #1 | side A length | 25 mm (≃0.98 in) |
| #2 | side A outer diameter | 48 mm (≃1 7/8 in) |
| #3 | side A thickness | 4 mm (≃0.16 in) |
| #4 | side B length | 30 mm (≃1 3/16 in) |
| #5 | side B outer diameter | 32 mm (≃1 1/4 in) |
| #6 | side B thickness | 3 mm (≃1/8 in) |
| #7 | transition length | 20 mm (≃0.79 in) |
| #8 | axis offset | 0 mm (0 in) |
| #9 | ends fillet | no fillet |
| Metadata | Value |
|---|---|
| inner diameter (side A) | 40 mm (≃1 9/16 in) |
| inner diameter (side B) | 26 mm (≃1.02 in) |
| total length | 75 mm (≃2 15/16 in) |
Parameter overview
Labels are used in the naming of the downloaded 3D files.
| Parameter | Label |
|---|---|
| #1 side A length | lenA |
| #2 side A outer diameter | diA |
| #3 side A thickness | thA |
| #4 side B length | lenB |
| #5 side B outer diameter | diB |
| #6 side B thickness | thB |
| #7 transition length | tra |
| #8 axis offset | ofs |
| #9 ends fillet | fil |
