Custom Tubing adapter STL file ⌀ 183–97 mm (Length: 117 mm) 📦#3859

STL Download STL
Create a new model:
from scratch search for a model
Tube adapter ⌀183 mm to ⌀97 mm in STL 3D format. Final length of this junction is 117 mm. The thickness of the tubes is identical: 3 mm. The larger-diameter tube has a length of 50 mm, the smaller one of 17 mm. The ends are rounded on the inside to make tube connection easier.
Generation date: 2025-11-27
3D Model Tubing adapter STL file ⌀ 183–97 mm (Length: 117 mm)

3D model download

Free
  • inline-tube-adapter-lenA50mm-d_model3859-nb0_dd{id}.stl : 6.8 Mo
STL Mesh quality : Linear deflection 0.05 Angular deflection 0.05
No compliance warranty No compliance warranty
(attribution - commercial use allowed)
Safe download
Instant .zip download — no email, no account

Values for this model

This model was generated by the Inline tube adapter template, with the following values:
Parameter Value
#1 side A length 50 mm (≃1.97 in)
#2 side A outer diameter 183 mm (≃7.20 in)
#3 side A thickness 3 mm (≃1/8 in)
#4 side B length 17 mm (≃0.67 in)
#5 side B outer diameter 97 mm (≃3 13/16 in)
#6 side B thickness 3 mm (≃1/8 in)
#7 transition length 50 mm (≃1.97 in)
#8 axis offset 0 mm (0 in)
#9 ends fillet fillet on the inside
Metadata Value
inner diameter (side A) 177 mm (≃6.97 in)
inner diameter (side B) 91 mm (≃3.58 in)
total length 117 mm (≃4.61 in)
illustration of the parameters
Parameter overview

Labels are used in the naming of the downloaded 3D files.

Parameter Label
#1 side A length lenA
#2 side A outer diameter diA
#3 side A thickness thA
#4 side B length lenB
#5 side B outer diameter diB
#6 side B thickness thB
#7 transition length tra
#8 axis offset ofs
#9 ends fillet fil
